Kayak Fish Rod Rack: A Comprehensive Guide

by

Summary

Kayak fishing is a thrilling and versatile sport that allows anglers to access remote fishing spots and target a variety of species. To make the most of your kayak fishing experience, a well-designed and properly installed rod holder system is essential. In this comprehensive guide, we’ll explore the step-by-step process of mounting a kayak rod holder track, provide instructions for making your own rod holder, and discuss the best locations to position your rod holders for optimal accessibility and balance.

How to Mount a Kayak Rod Holder Track?

kayak fish rod rack

Step-by-Step Instructions for Mounting a Kayak Rod Holder Track

Materials Needed:
– Rod holder track or base (e.g., Scotty flush mount base)
– Drill and drill bits (1 3/8″ hole saw or jigsaw)
– Rivets or stainless steel screws and nuts
– Sealant (e.g., Lexcel)
– Marker
– PVC or template for marking the hole
– Rasp (optional for fine-tuning the fit)

Tools Needed:
– Drill
– Jigsaw or hole saw
– Rivet gun or screwdriver
– Rasp
– Marker

Step-by-Step Process:

  1. Determine the Location: Choose a flat area on the kayak, typically behind the cockpit, to ensure stability and accessibility. Ensure the location allows you to reach the rod holder comfortably without interfering with your paddle stroke.

  2. Mark the Hole: Use a marker to mark the center point where you want to install the rod holder. If using a rod holder with a gasket, you can use the gasket as a template to draw the hole.

  3. Drill the Hole: Drill a pilot hole in the center of the marked area. Then, use a jigsaw or a 1 3/8″ hole saw to create the oblong hole for the rod holder. If necessary, use a rasp to fine-tune the fit.

  4. Test Fit the Rod Holder: Insert the rod holder into the hole to ensure it fits snugly. If it doesn’t fit, use a rasp to adjust the hole.

  5. Secure the Rod Holder: Apply a bead of sealant around the edge of the hole. Insert the rod holder and ensure it is at the desired angle. Drill holes for the rivets or screws and secure the rod holder using rivets or stainless steel screws and nuts.

  6. Final Check: Verify that the rod holder is securely attached and at the correct angle. Ensure there is no leakage around the installation.

How to Make Your Own Kayak Fishing Rod Holder?

While making your own rod holder from scratch is less common, you can create a simple one using available materials. Here’s a basic outline:

Materials Needed:
– PVC pipe or similar material for the rod holder tube
– PVC end cap or a wooden dowel for the rod rest
– Epoxy or strong adhesive
– Drill and drill bits
– Sandpaper
– Sealant (e.g., silicone)

Dimensions and Construction Steps:

  1. Cut the PVC Pipe: Cut a length of PVC pipe to the desired height for your rod holder. Typically, this would be around 6-8 inches long.

  2. Create the Rod Rest: Cut a PVC end cap or a wooden dowel to fit inside the top of the PVC pipe. This will serve as the rod rest. Glue it in place using epoxy or a strong adhesive.

  3. Drill Holes for Mounting: Drill holes at the base of the PVC pipe for mounting. These holes should align with the holes in the kayak where you will secure the rod holder.

  4. Sand and Finish: Sand the entire assembly to smooth out any rough edges. Apply a coat of sealant to protect the material and ensure a watertight fit.

  5. Mount the Rod Holder: Follow the same mounting steps as described above for a commercial rod holder, using rivets or screws to secure the homemade rod holder to the kayak.

Where is the Best Place to Mount a Rod Holder on a Kayak?

Optimal Locations:

  1. Behind the Cockpit: This is the most common location, providing easy access and minimal interference with paddling. Ensure the rod holders are at a comfortable angle and height.

  2. Accessibility and Balance: The rod holders should be within easy reach to allow quick retrieval and storage of rods. They should not interfere with your paddle stroke or the stability of the kayak.

  3. Measurements and Angles: The angle of the rod holder is crucial. Typically, a 30-degree angle is recommended to ensure the rod rests securely. Use a PVC piece cut at this angle as a template to mark the hole. Ensure the rod holders are symmetrical to maintain balance and stability.
